LM Series Vertical Roller Mill
Capacity: 10-320TPHLM Vertical Roller Mill integrates crushing, drying, grinding, classifying and conveying together, and it is specialized in processing non-metallic minerals, pulverized coal and slag. Its coverage area is reduced by 50% compared with ball mill, and the energy consumption is saved by 30%-40% similarly. It is used to grind granular and powdered materials into powder with required fineness.
What LM Series Vertical Roller Mill Plant Can do ?
Bentonite
Plaster
calcium carbonate
Processed Materials: Limestone, calcite, calcium carbonate, barite, talc, gypsum, bentonite, quartz, feldspar, talc, marble, bauxite, slag, dolomite, granite, clay, kaolin, basalt, graphite, coal, petroleum coke, gold ore, etc.
Output Size(mm): such as 0-3mm Coarse Powder, 20-400mesh（0.8-0.038mm, 400-3250mesh（38-3μm）, 3250mesh Powder.
Widely Applications
limestone desulfurization in power plant, metallurgy, non-metallic mineral powder making, non-metallic ore pulverizing, heavy calcium carbonate processing, building materials and chemical industry, coal, ceramics, cement, etc.
Top 5 Advantages of LM Series Vertical Roller Mill
Low Investment Cost. It can be installed outside, so it will reduce a large number of investment costs.
Low Operation Cost. Compared with ball mill, it saves energy consumption by 30%-40%.
Simple and reliable operation. It is equipped with automatic control systems, so remote control makes it easy to operate.
Maintenance convenience. By repairing fuel tank, rotating the arm, it is fast to replace the roller sleeve, and liner, and reduce the downtime loss.
Environmental protection. It is with small vibration, low noise, and the overall sealing.
Technical Data
| Model | Capacity (t/h) | Max.input size (mm) | Output fineness | |
| micron | mesh | |||
| LM370K | 90~320 | <65 | 170~45 | 80~325 |
| LM340K | 70~260 | <62 | 170~45 | 80~325 |
| LM280K | 50~196 | <58 | 170~45 | 80~325 |
| LM240K | 41~128 | <55 | 170~45 | 80~325 |
| LM220K | 36~114 | <45 | 170~45 | 80~325 |
| LM190K | 23~72 | <40 | 170~45 | 80~325 |
| LM170K | 18~57 | <42 | 170~45 | 80~325 |
| LM150K | 13~40 | <40 | 170~45 | 80~325 |
| LM130K | 10~30 | <38 | 170~45 | 80~325 |
Successful Project Case
15tph coal powder grinding line in china
- Equipment: LM1300M vertical roller mill
-
Consulting
- Processed material: coal powder
- Capacity: 10-15T/H
- Input Size: 0-700mm
- Output Size: 200 mesh, D80
- Application: pulverized coal preparation
